How to Flash Lenovo TB2-X30F and Fix Boot Loop / Hang on Logo Using QFIL
Flashing the stock firmware using the Qualcomm Flash Image Loader (QFIL) tool is the most reliable way to repair software-related issues on the Lenovo Tab 2 A10-30 (TB2-X30F). This process completely overwrites corrupted system partitions, successfully reviving tablets experiencing an unconditional hang on the logo, a continuous boot loop, or random restarts during start-up.
Lenovo Tab 2 A10-30 (TB2-X30F) Specifications:-
- Display: 10.1-inch IPS LCD | 1280 x 800 pixels (HD)
- Processor: Qualcomm Snapdragon 210 (MSM8909) | Quad-core 1.3 GHz
- Memory: 1 GB or 2 GB RAM (variant dependent)
- Storage: 16 GB internal | MicroSD expandable up to 64 GB
- Operating System: Android 5.1 (Lollipop) upgradeable to Android 6.0 (Marshmallow)
- Cameras: 5 MP autofocus rear camera | 2 MP fixed-focus front camera
- Battery: 7000 mAh non-removable Li-Ion
- Connectivity: Wi-Fi 802.11 b/g/n | Bluetooth 4.0 | Micro-USB 2.0
Prerequisites & Downloads:-
Before getting started, make sure your Windows PC is prepared with the necessary software files:
-
- Lenovo TB2-X30F Stock ROM: Download the official firmware file specific to your region. Extract the package to an easy-to-reach directory on your PC (e.g.,
C:\Lenovo_Firmware). - QPST/QFIL Tool: Download and install the latest stable version of the QPST Flash Tool suite which includes the standalone QFIL application.
- Qualcomm USB Drivers: Install the correct Qualcomm HS-USB QDLoader 9008 drivers to ensure your computer detects your tablet when it enters its emergency download interface.
- Hardware Requirements: A high-quality Micro-USB cable and a laptop/PC running Windows 7, 10, or 11. Ensure the tablet’s battery has at least a 50% charge.
- Lenovo TB2-X30F Stock ROM: Download the official firmware file specific to your region. Extract the package to an easy-to-reach directory on your PC (e.g.,
Step-by-Step Guide to Flashing the Firmware:-
Step 1:- Boot the Tablet into EDL Mode (Qualcomm 9008)
-
- Power off your Lenovo TB2-X30F tablet completely.
- Press and hold both the Volume Up and Volume Down buttons simultaneously.
- While holding both buttons down, insert the USB cable connected to your computer into the tablet.
- Release the buttons. The screen will remain black, but your PC should sound a connection chime.
- Verify the connection by opening Device Manager on your PC. Under ports, it should display Qualcomm HS-USB QDLoader 9008 (COMXX).
Step 2:- Configure the QFIL Tool
-
- Launch the QFIL Tool application from your Windows Start Menu.
- At the top of the interface, look for the text field displaying your connection status. If configured correctly, it will read Qualcomm HS-USB QDLoader 9008.
- Under Select Build Type, click on the Flat Build.
- In the Select Programmer section, click Browse…. Navigate into your extracted stock firmware folder and choose the programmer file (usually named
prog_emmc_firehose_8909.mbnor similar for this specific chipset architecture). - Click the Load XML… button.
- QFIL will prompt you for two specific layout structures. Select rawprogram0.xml first, immediately followed by the patch0.xml layout mapping file when the second prompt opens up.
- If you want to watch video tutorial guide:- Watch Now
Step 3:- Initiate the Flashing Protocol
- Double-check that all paths are correctly pointed towards your extracted software components.
- Click the blue Download button located at the bottom of the interface to initiate flashing.
- The progress bar will start moving, and text logs will fill the status panel at the bottom. Do not disturb the USB cable or close the program during this phase.
- Once the process completes successfully, the status box will echo the confirmation log:
Download Succeed/Finish Download.
